Fuel Tracker

-- ----Z ----L | JD---

CAO 18AUG26

simbaops.com

TOT OFF --

RCVR'S --

CONT --

Install App Use offline.

Update Available Refresh app.

Receivers

No receivers yet Tap the plus button to log the first offload.

Add Receiver

Date (Zulu) Synced to now

Callsign

Tail

Type

Burn Rate

K/hr

Fuel Start

K

Fuel End

K

Fuel Offloaded

K

Time on Boom

mmss

Contacts

ct

Notes

Fuel Offloaded 0.0 K

Start - End - (Boom Time x Burn Rate)

Install App

iPhone and iPad: tap Share, then Add to Home Screen. Android and desktop browsers may show an install confirmation after tapping Install App.

Filter

Search

From (Zulu)

To (Zulu)

Fill out only the filter boxes you want to use.

SIMBA Assist

Turn Range & Offset

Receiver Type

RDVZ KIAS

KIAS

AR Altitude

FL

Tanker KIAS

KIAS

IP → CP CRS

°

Orbit

Wind

Wind Components

HW -- XW --

Turn Range--

Offset--

Tanker Alt--

Receiver Alt--

Tanker TAS--

Receiver TAS--

Closure--

Drift--

40 NM 🚫🌬️--

30 NM 🚫🌬️--

40 NM --

30 NM --

Overrun--

Rate of Turn--

180° Turn Time--

SR Bank / ½ Bank--/--

Timer0:00

25° AOB • Standard atmosphereWIND OVERRIDE - SCROLL OFF

XW--

HW--

Angle--

IP → CP --° Wind -- Orbit Left

Ground Track Orbit Diameter

Altitude

FL

Airspeed -- KTAS

KIAS

Wind GS ---–--- KT

Wait Time

mmss

15° Max Bank--360° -- • --° Min • --° Avg

20° Max Bank--360° -- • --° Min • --° Avg

25° Max Bank--360° -- • --° Min • --° Avg

30° Max Bank--360° -- • --° Min • --° Avg

No closed ground-circle solution

Frag Calc

T/O Fuel

K

Land Fuel

K

Flight Time

hhmm

Burn Rate

K/hr

Offload

K

Frag --

T/O - Land - (Flight Time × Burn Rate) - Offload

Main Tank Burn Time -- / --

Amount to Burn

K

1 Eng Burn Rate

K/hr

Amount to burn / burn rate x 60

KC135 Fuel Reference

Mains → AB ~1.3K PPM

1 Main → AB ~1K PPM

CW → FB ~2.3K PPM

UD → AB ~1.4K PPM

Moving Fuel ~23 CG Shift

AFT CG Fuel Efficient (±32% MAC)

FWD CG More Stable

KC135 CG Calc Estimate

FB MAX ~39K

CW MAX ~49K

AB MAX ~43K

RES MAX ~3K

UD MAX ~15K

Main 1/4 MAX ~14K Main 2/3 MAX ~15K

CG (%MAC) --

33 - FB - 13(CW) + 23(AB + RES) + 32(UD)

ALT CG (%MAC) --

33 - FB - 13(CW) + 23(AB) + 43(RES) UD

Add Receiver Type

Receiver Type

RDVZ KIAS

KIAS

Select Receiver

US National SRD • 1 AUG 2026

Table 2-4 - KIAS to TAS Conversion

Table 2-8 - 25° AOB Turn Range

Table 2-9 - 25° AOB Offset

Table 2-13 - Timing Chart (Nil Wind)

Quick Notes

Yellow boxes mark the published cells used. Two or four boxes indicate interpolation.
TAS uses standard atmosphere; receiver altitude is modeled 1,000 feet below tanker altitude.
Turn range and offset use the 25° AOB tables and ARIP-to-ARCP course drift.
Chart timing is nil wind. Wind-symbol timing in the calculator is supplemental.
A yellow ~ marks limited extrapolation; farther values display OUT OF RANGE.

Confirm
